| Prod Model: |
SLP-2103 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frame Material: |
Aluminum 6061/T6(13hw) |
| Frame Finishing: |
Fluorine Carbon Paint Coating(PVDF) |
| Roof Fabric: |
850g/Sqm PVC (Blackout) |
| Sidewalls Fabric: |
650g/Sqm PVC (Half Blackout) |
| PVC Function: |
Waterproof/Fireproof/UV Proof |
| Fire Resistance: |
DIN4102 B1/M2(Europe Standard) |
| Max Allow Wind Speed: |
100km/Hour |
| Top Style: |
Ridge Tent |
| Capacity: |
>10 |
| Material: |
PVC |
| Usage: |
Wedding |
| Pole Material: |
Flexible Poles,aluminium Alloys |
| Structure: |
Single Skin |
| Color: |
White |
| Waterproof: |
Waterproof |
| Customized: |
Customized |
| Style: |
Non |
| Season: |
All |
Product Description
100% relocatable and unobstructed free span space;
Very easy and very fast to install and dismantle, convenient to stock and transport
Rainproof, fire retardant, UV-protection, can be environmentally controlled in any climate
1. SPECIFICATION1) Span width: Any size between 3m and 40m
2) Length: No limite, extended by 5m, such as 20m, 25m, 30m 40m^
3) Bay distance: 3m / 5m
4) Eave height: 2.5m / 4m
2. FRAME PART1) The main parts are made of aluminum alloy and the spare parts are made of steel.
2) All aluminum components are technically anodized and all steel parts are well hot-DIP galvanized.
3. COVER PART1) The roof and sidewall fabric cover are made of double PVC coated polyester textile.
2) The fabric is good at waterproof and UV resistant.
3) The fabric is flame retardant to DIN4102, M2, Grade B1.
4) The weight of fabric is from 660g/sq. M to 850g/sq. M.
4. OPTIONAL ACCESSORY1) Sidewall with clear PVC window. 2) Rain gutter 3) Glass door and Glass wall.
4) Lining for decorating the tent.
5. FEATURE1) Easy to assemble and dismantle.
2) Small storage volume.
3) No pole inside, 100% space is available.
| Product specification | Span width(m) | Bay spacing(m) | Eave height(m) | Ridge height(m) |
Main frame profile
(mm) |
| SBLP-3 | 3 | 3 | 2.5 | 3 | 48x84x3.0 |
| SBLP-6 | 6 | 3 | 2.5 | 3.5 | 48x84x3.0 |
| SBLP-8 | 8 | 3 | 2.5 | 3.9 | 48x84x3.0 |
| SBLP-10 | 10 | 3 | 2.5 | 4.3 | 48x84x3.0 |
| SBLP-15 | 15 | 5 | 4 | 6.4 | 150x108x3.0 |
| SBLP-18 | 18 | 5 | 4 | 6.9 | 203x112x4.5 |
| SBLP-21 | 21 | 5 | 4 | 7.4 | 203x112x4.5 |
| SBLP-25 | 25 | 5 | 4 | 8.0 | 203x112x4.5 |
| SBLP-30 | 30 | 5 | 4 | 8.8 | 113x259x5.5 |
Related Products
Our Company
Changzhou Expo Tent Co., Ltd. is a company specialized in the research, development, sales and rent of the tent. The company has an excellent team with advanced technology and good service. They are committed to be a best tent company in China.
Changhou Expo Tent Co., Ltd established in 2010, is a leading China tent company in designing, manufacturing, developing selling and renting aluminum and steel frame fabric structures, tents and marquees. With our structures, we offer turnkey solutions for temporary, semi-permanent and permanent use for a variety of industries: Fabric structures for retail and logistics, sports buildings and indoor training facilities, tents and marquees for all sorts of events and tent sales.
With few years' effort, the company has developed one-piece tent that the biggest span width can be 40m, tent with cuspidal head (the biggest can be 10m*10m) and non-standard shape tent. The products are well sold to Asian, European and USA, and it has built good reputation among the customers in China and oversea.
For the development of our products we make use of the latest technologies. Our structures meet the strictest and most recent standards and come in all sizes and shapes. We are able to satisfy the most demanding clients in over 40 countries worldwide. With our experienced team, we know our business inside and out.
Expo employees will make every effort to improve their product quality and built their own brand. Welcome you come to visit.
Contact us for more info about our tents, marquees and halls.
